DESCRIPTION

Basic Info.

Model NO.	CYKY-BTF-500
Crucibles	Quartz Crucible or Bn Crucible
Melting Sample Quantity	10 - 50g (Depending on The Material)
Weight	~800kg
Dimension	2000*1100*1800mm(L*W*H)
Vacuum	5 *10 E-5 Torr (Within 20 Minutes)
Heating Power	15kw
Vacuum Chamber Size	Diameter 500mm * 400mm L
Transport Package	Standard Export Wooden Packaging
Specification	2000*1100*1800mm
Trademark	CYKY
Origin	Zhengzhou Henan China
HS Code	85141090
Production Capacity	500 Sets Per Month

Product Description

lab-scale vacuum melt spinning system for preparing amorphous metallic ribbons
Description of Vacuum Melt Spinning SystemA lab-scale vacuum melt spinning system for preparing amorphous metallic ribbons. In this technique, metal ingots (<50g) are melted via induction heating method and then propelled by over-pressurizing the crucible. Specification of Vacuum Melt Spinning System:

Feature	The complete system consists of the stainless steel vacuum chamber, vacuum system, induction heating system, rack system and discharging tubular collector.Copper roller linear speed: 5 ~ 60m / SMelting metallic samples: 5g ~ 50g/Per batchVacuum casting device (not included in standard configuration)
Power supply	Voltage: AC380V, three-phaseMaximum power 15kw (60A air switch required)
Vacuum chamber & vacuum pump	Vacuum chamber size: Φ 500mm x 400mm LHinged cavity door with quartz observation windowMolecular pump system is installed in the equipmentVacuum: 5 X10 E-5 Torr (within 20 minutes)Limiting vacuum 10e-7 Torr (to be baked)
Induction heater & temp Controller	Heating power: 15kw; frequency range: 30 ~ 80kHzMelting sample quantity: 10 - 50g (depending on the material)Accurate temperature control system, B-type thermocouple, 30 temperature rise and fall procedures can be setTemperature control accuracy: + / - 2 ºC
Crucibles	Quartz crucible or BN crucible can be used according to customers' requirements
Spinning wheel	Standard copper roller cooling without waterLinear speed of copper roller: 5 ~ 60m / SOptional:Optional water-cooled copper roller with a maximum sample handling capacity of 500gOptional vacuum casting module
Optional accessories	Casting accessories (casting, spray casting) can be purchased according to requirementsThe water cooling system can be customized for the casting copper mold according to the requirements
Dimension	2000×1100×1800mm(L×W×H)
Weight	~800Kg
Certificate	CE certification

Reference picture of Vacuum Melt Spinning System:

Q. Are you a manufacturer or a trading company?

A. We are professional laboratory instrument manufacturers, have their own design team and factory, have mature technical experience, and can guarantee the quality of products and the optimal price.

Q. How is your company's product after-sales service system?

A. The product warranty period is 12 months, we can provide lifetime maintenance. We have professional pre-sales and after-sales departments that can respond to you within 24 hours to resolve any technical issues.

Q. How long is your delivery time? If I want to customize the instrument, how long does it take?

A.1. If the goods are in stock, it is 5-10 days. 2. We can provide customized services for our customers. It usually takes 30-60 days depending on the specifications of the custom instrument.

Q. Our country's power supply and plug are different. How do you solve it?

A. We can supply a transformer and plug according to your local requirements according to the power plug of different countries.

Q. How to pay?

A.T / T, L / C, D / P, etc., it is recommended to use Alibaba Trade Guarantee.

Q. How is the package of goods? Delivery methods?

A.1. Standard export fumigation sign wooden box packaging 2. Express, air, sea shipping according to customer requirements, find the most suitable way.

More questions, please contact customer service
